FS3500 E FS3500 E, 2018-06

Hover mouse on parts list

Wheel: Zoom, left button: Movement

Other parts For FS3500 E, 2018-06

21/23 SPEED CONTROL

22/23 STARTER

23/23 TRANSMISSION

1	TBD 30HP 1800 575V/60/3 30HP 1800 575V/60/3	542183335
2	STARTER Compl (lncls ltms 3 - 6) Enclosure, 16x12 Compl (lncls ltms 3 - 6) Enclosure, 16x12	542182187
3	MOTOR STARTER Magnetic 230 - 460V Magnetic 230 - 460V	542182188
4	RELAY Overload Overload	542182189
5	TBD Button, Reset (Thru-Door) Button, Reset (Thru-Door)	542176941
6	TBD Reset Button Reset Button	542176940
7	TBD Hex Hd, M8 x 1.25 x 40 DIN933 Hex Hd, M8 x 1.25 x 40 DIN933	542197228
8	GROMMET .312 x .75 x .18 .312 x .75 x .18	542166898
9	WASHER Flat M8	542173059
10	NUT Hex M8 DIN934	542172027
11	NUT Fiber M8 DIN 985	542139738
12	TRANSFORMER Current Current	542176914
13	CONDUIT END FITTING Seal Tight 45 Deg - 3/4" Seal Tight 45 Deg - 3/4"	542176938
14	CONDUIT END FITTING Conduit Reducing Conduit Reducing	542183540
15	LOCK NUT Conduit - 3/4"	542176953
16	CONDUIT END FITTING Conduit 1"x" Conduit 1"x"	542176939
17	SEALING RING 3/4" Sealing Ring - 3/4"	542176933
18	CONDUIT END FITTING Relief, Strain, Water Tight - 3/4" Relief, Strain, Water Tight - 3/4"	542046748
20	TBD Relief, Strain, Water Tight - 1", X-Dia (20HP-Std) Relief, Strain, Water Tight - 1", X-Dia (20HP-Std)	542183432
21	CONDUIT END FITTING 1" 1"	542176934
22	TBD Conduit - 1" Conduit - 1"	542176954
23	CONTROL CABLE	542176913
34	CLAMP Vinyl Coated 3/8 x 1.0"	542166955
35	TBD Plug, Twist Lock, 575V (30HP-Std) Plug, Twist Lock, 575V (30HP-Std)	542176945
36	TBD Connector.Twist Lock, 575V (30HP-Std) Connector.Twist Lock, 575V (30HP-Std)	542176944
37	CABLE SLEEVE Support, Bus Drop, Cable Support, Bus Drop, Cable	542176950
38	OPERATOR´S MANUAL Operator's Manual: FS3500	502610301
