Spare parts > Husqvarna > ENGINES & TRANSMISSIONS > KOHLER ENGINES KOHLER COURAGE 15 HP, SV470-0104, 2009-01 > FUEL SYSTEM
Back to
FUEL SYSTEM
KOHLER ENGINES KOHLER COURAGE 15 HP, SV470-0104, 2009-01
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For KOHLER COURAGE 15 HP, SV470-0104, 2009-01
1 GASKET 504577501
2 PEN 504577701
3 KIT 523060801
4 PODLOŽKA 531029606
5 SCREW 531029597
6 CARBURETTOR (Includes Key Numbers 7 and 8) 531029941
7 GASKET 531029599
8 GASKET 531029600
9 ŠROUB 531029601
10 MATICE 531029602
11 HOSE "(Fuel line comes in lengths of 24"" - cut to needed lengths for carburetor connections)" 531029987
12 CLAMP 531029604
13 FILTER 531029502
GASKET KIT 544368901
