Spare parts > STIGA > Lawn Mower > TURBO 510S TURBO 510S (1993) [12-7218-17] > Wheel Suspension (Aluminium-Wheels) Handlebar
Back to
Wheel Suspension (Aluminium-Wheels) Handlebar
TURBO 510S TURBO 510S (1993) [12-7218-17]
Hover mouse on parts list
Wheel: Zoom, left button: Movement
Other parts For TURBO 510S (1993) [12-7218-17]
1 Front Axle 1111-2254-01
2 Bushing 1111-1067-02
3 Clamp Front 1111-1706-01
4 Screw 9943-0512-16
5 Rear axle 1111-2343-01
6 Clamp Rear 1111-1072-01
7 Screw 9947-0616-16
8 Spring 1111-1074-01
9 Lever 1111-2444-02
10 Screw 9997-0612-16
11 Nut 9739-0631-22
12 Tension Rod 1111-2264-01
13 Starlock 9675-0011-00
14 Screw 9836-9520-12
15 Screw 9943-0612-16
16 Washer 9699-0037-02
17 Cover Plate 1111-2141-01
18 Spring 1111-2183-01
19 Cover Plate 1111-2108-01
21 Ball Bearing 9549-0001-00
22 Flat washer 9699-0100-02
23 Hub Cap 1111-2077-01
24 Washer 1111-1638-01
25 Locking handle 1111-1016-01
26 Pin 9595-0235-00
27 Tension Rod 1111-1087-02
28 Nut 9739-0831-22
29 Screw 9942-0816-16
30 Handle attachment 1111-1078-01
31 Adjusting Plate 1111-1019-01
32 Screw 9997-0816-16
33 Nut 9747-0831-02
34 Knob 1111-0035-01
35 Reinforcement 1111-0178-00
36 Washer 9699-0025-02
37 Screw 9899-3551-12
38 Cable Holder 1111-2018-01
39 Screw 9836-9216-12
40 Handle Lower Part 1111-1076-01
41 Handlebar 1111-2003-01
42 Screw 9841-0410-16
45 Gear Ring 1111-2109-01
46 Spacer 1111-2250-01
47 Grip 1111-2445-01
48 Throttle Cable 1111-2365-02
71 Gear Wheel 1111-2083-02
72 Pin 1111-2382-01
73 Washer 1111-1456-01
75 Attachment plate 1111-2010-01
76 Screw 9849-7909-16
77 Control Cable 1111-1197-03
78 Nut 9739-0631-22
79 Spring 1482-0160-01
80 Control Handle 1111-1998-01
81 Screw 9948-0645-16
82 Nut 9799-0631-02
20B Rear Wheel 1111-2345-01
20F Wheel 1111-2346-01
