Husqvarna Construction Products
>
TROWELS
>
CRT 48 PS CRT 48 PS
>
GEARBOX, RIGHT
Back to
CRT 48 PS
CRT 48 PS
GEARBOX, RIGHT
CRT 48 PS
CRT 48 PS
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
CRT 48 PS
101
HUB
599074901
103
HOLDER
598999401
104
YOKE
598999001
105
LINK
598993301
106
TUBE
598993401
107
CAP
24Nm/18ft.lbs (S1)
598998701
108
SHAFT
599107701
109
WASHER
599166001
110
PLUG
598995801
111
SHAFT
599167801
112
RING
Blade lifting ring, left
599001101
115
BLADE SET
Finishing blades 48", set of 4 pcs.
598929801
120
RING
599013201
170
PLUG
599163401
200
MOUNT
598993501
284
CAP
Cap
599169201
414
SCREW
5/16"-18x1-5/8" HHCS GR5, 24Nm/18ft.lbs
599167101
420
SCREW
1/2"x1/2" shoulder, 24Nm/18ft.lb
599163001
424
SCREW
M10x35 ISO4017 8.8 ZPB, 49, Nm/36ft.lbs
725249751
444
SCREW
1/2"x3/4"x1-3/8" shoulder, 24Nm/18ft.lb
599165001
445
SCREW EHHM
M10 x 45, 49Nm/36ft.lbs (DIN931 S3)
725250051
456
HEXAGON NUT
596040201
484
WASHER
M20 ISO7089 200HV ZPB
542173035
514
PIN
Cotter pin 1/8"x 1-1/2"
599164901
516
PIN
Cotter pin 3/16"x2"
599165101
590
BUSHING
598999101
613
FITTING
Grease fitting AM10 DIN71412
599162101
701
BALL BEARING
6014 2RS1 C3
598431901
702
RING
Nilos ring 6014 ZAV
599167201
