Spare parts
>
McCULLOCH
>
TRIMMERS/EDGERS
>
MT250LK MT 250 LK, 966553501, 2011-12
>
ENGINE
Back to
MT250LK
MT 250 LK, 966553501, 2011-12
ENGINE
MT250LK
MT 250 LK, 966553501, 2011-12
Hover mouse on parts list
Wheel:
Zoom, left button:
Movement
Other parts
For
MT 250 LK, 966553501, 2011-12
1
SCREW
530015886
2
BOLT
530058982
3
ASSY MUFFLER/SHIELD
545227901
4
SCREW
530016341
5
PLUG SPARK (RCJ6-Y) Accy - Spark Plug (RCJ6-Y)
RCJ-6Y
952030249
6
CYLINDER
529293401
7
GASKET KIT
530071750
8
PISTON RING
545154001
9
CIRCLIP
530015162
10
KIT PISTON
530071357
11
CRANKSHAFT ASSY
530057829
12
CRANKCASE ASSY
529274501
13
GASKET KIT
530071750
14
ADAPTER
530057547
15
SCREW
530016441
16
GASKET KIT
530071750
17
CARBURETTOR
530071822
18
AIR BOX
530059267
19
SCREW
530016429
20
AIR FILTER
530057781
21
COVER
530057584
22
IGNITION MODULE
545215801
23
DRIVE COUPLING
530038604
24
SCREW
530016357
25
KIT
579571601
26
SCREW
530016392
27
COVER
545010601
28
STARTER HANDLE
530027569
29
KIT
530071767
30
SCREW
530016386
31
NUT
530016124
32
CLIP
530057588
33
SCREW
530016430
34
RETURN SPRING
530042085
35
KIT
530071786
36
RETAINER
530027523
37
SCREW
530015775
38
PODLOŽKA Washer
530015828
39
FLYWHEEL ASSY
545221701
40
KIT
577805101
41
CLIP
530015941
42
BEARING
530055728
43
SEAL
530019264
44
BEARING
530032125
45
CONNECTING ROD
530069945
46
PISTON
530071785
47
GASKET KIT
530071750
48
PLUG
530057954
49
SCREW
530016386
50
SHROUD--REAR,
545011001
51
SCREW FUEL TANK RETAINER
530016445
52
FUEL TANK ASSY
530058712
53
TANK
530014347
54
HOSE
530069247
55
KIT
530069216
56
FILTER
530095646
57
GASKET KIT
530071750
CHOKE LEVER
NOT SHOWN
545212602
